GEK-106310AE F650 Digital Bay Controller 3-75
3 HUMAN INTERFACES. SETTINGS & ACTUAL VALUES 3.2 HUMAN MACHINE INTERFACE (HMI)
3
Esc: Exit Text.
The ESC option returns to the general I/O board menu.
Enter: Chg Input.
Pressing the enter/shuttle key on the blinking input, this input will be activated in emulation mode.
Note: input emulation can only be executed through the TEST INPUT tool on the graphic display.
<TEST OUTPUT>
This option allows testing the output activation in emulation mode. The displayed screen is similar to the viewing
screen, but in this case the user can operate the different relay contact outputs to test the wiring.
This screen shows the Output name lit up, showing that this is an output emulation mode.
The first relay output will appear blinking and between brackets; the user can select a different output by pressing the
up-down key or rotating the shuttle key. When the enter/shuttle key is pressed, the selected output will be activated.
Navigation through this screen is indicated by the following legend:
Esc: Exit Text. Enter: Chg Output.
Esc: Exit Text.
The ESC option returns to the general I/O board menu.
Enter: Chg Output.
Pressing the enter/shuttle key on the blinking output, this output will be activated in emulation mode.
Note: Output emulation can be executed through the TEST OUTPUT tool on the graphic display, and also
through communications using EnerVista 650 Setup software for all F650 models.
: Chg Card
Pressing the up-down key or rotating the shuttle key allows to change the selected I/O board in the main I/O screen.
