GEK-113000AE F650 Digital Bay Controller A-35
APPENDIX A A.1 LOGIC OPERANDS
A
OPERANDS - F650 - MODEL FX - GX
INTERNAL SYSTEM STATUS (CONT.)
Remote Outputs
DNA 1
1 output on. Remote Output DNA 1 Operation (GSSE/
GOOSE)
DNA 2
1 output on. Remote Output DNA 2 Operation (GSSE/
GOOSE)
... ...
DNA 32
1 output on. Remote Output DNA 32 Operation (GSSE/
GOOSE)
User St 1
1 output on. Remote Output UserSt 1 Operation (GSSE/
GOOSE)
User St 2
1 output on. Remote Output UserSt 2 Operation (GSSE/
GOOSE)
... ...
User St 64
1 output on. Remote Output UserSt 64 Operation
(GSSE/GOOSE)
Rem GOOSE Dig Out 1
1 output on. Remote Output GOOSE 1 Operation
(GOOSE)
Rem GOOSE Dig Out 2
1 output on. Remote Output GOOSE 2 Operation
(GOOSE)
... ...
Rem GOOSE Dig Out 32
1 output on. Remote Output GOOSE 32 Operation
(GOOSE)
Remote Inputs
Remote Input 1 Flag is set, logic =1
Remote Input 2 Flag is set, logic =1
... ...
Remote Input 32 Flag is set, logic =1
Remote Devices
Remote Device 1 Flag is set, logic =1
Remote Device 2 Flag is set, logic =1
... ...
Remote Device 16 Flag is set, logic =1
GOOSE DIG INPUTS
Rem GOOSE Dig Input 1 Flag is set, logic = 1
Rem GOOSE Dig Input 2 Flag is set, logic =1
... ...
Rem GOOSE Dig Input
32
Flag is set, logic =1
GOOSE Analog Inputs (FLOAT AND INTEGER)
Rem Ana Inp FLOAT 1 Analog Input 1 (Float type)
Rem Ana Inp FLOAT 2 Analog Input 2 (Float type)
... ...
Rem Ana Inp FLOAT 8 Analog Input 8 (Float type)
Rem Ana Inp INT 1 Analog Input 1 (Integer type)
Rem Ana Inp INT 2 Analog Input 2 (Integer type)
... ...
Rem Ana Inp INT 8 Analog Input 8 (Integer type)

GE F650 Specifications

General

Model	F650
Category	Controller
Frequency	50/60 Hz
Display	LCD
Type	Feeder Protection Relay
Application	Feeder Protection and Control
Communication Protocols	DNP3, Modbus, IEC 61850
Protection Functions	Overcurrent, Earth Fault
Manufacturer	General Electric
Input Voltage	24-250 VDC/VAC
