GEK-113000AE F650 Digital Bay Controller D-5
APPENDIX D D.1 FACTORY DEFAULT SETTINGS
D
PRODUCT SETUP>COMMUNICATION SETTINGS >DNP3 SLAVE (CONT.)
DNP3 SLAVE 1 > DNP3 SLAVE 2 > DNP3 SLAVE 3
SETTING DESCRIPTION NAME DEFAULT VALUE STEP RANGE
USER
VALUE
DNP Analog Input Points point list Analog Input Point 7 End of list N/A
DNP Analog Input Points point list Analog Input Point 8 End of list N/A
DNP Analog Input Points point list Analog Input Point 9 End of list N/A
DNP Analog Input Points point list Analog Input Point 10 End of list N/A
DNP Analog Input Points point list Analog Input Point 11 End of list N/A
DNP Analog Input Points point list Analog Input Point 12 End of list N/A
DNP Analog Input Points point list Analog Input Point 13 End of list N/A
DNP Analog Input Points point list Analog Input Point 14 End of list N/A
DNP Analog Input Points point list Analog Input Point 15 End of list N/A
DNP Analog Input Points point list Analog Input Point 16 End of list N/A
DNP Analog Input Points point list Analog Input Point 17 End of list N/A
DNP Analog Input Points point list Analog Input Point 18 End of list N/A
DNP Analog Input Points point list Analog Input Point 19 End of list N/A
DNP Analog Input Points point list Analog Input Point 20 End of list N/A
DNP Analog Input Points point list Analog Input Point 21 End of list N/A
DNP Analog Input Points point list Analog Input Point 22 End of list N/A
DNP Analog Input Points point list Analog Input Point 23 End of list N/A
DNP Analog Input Points point list Analog Input Point 24 End of list N/A
DNP Analog Input Points point list Analog Input Point 25 End of list N/A
DNP Analog Input Points point list Analog Input Point 26 End of list N/A
DNP Analog Input Points point list Analog Input Point 27 End of list N/A
DNP Analog Input Points point list Analog Input Point 28 End of list N/A
DNP Analog Input Points point list Analog Input Point 29 End of list N/A
DNP Analog Input Points point list Analog Input Point 30 End of list N/A
DNP Analog Input Points point list Analog Input Point 31 End of list N/A
DNP NOTES
Note 1: Scale Factor
Note that a scale factor of 0.1 is equivalent to a multiplier of 10 (i.e. the value will be 10 times
Note 2: Binary Input Block Selection:
[NOT USED, CTL EVENTS 1-16, CTL EVENTS 17-32, CTL EVENTS 33-48,CTL EVENTS 49-
64, CTL EVENTS 65-80, CTL EVENTS 81-96, CTL EVENTS 97-112, CTL EVENTS 113-128,
SWITCHGEAR 1-8, SWITCHGEAR 9-16]
PRODUCT SETUP>COMMUNICATION SETTINGS >IEC 870-5-104
SETTING DESCRIPTION NAME DEFAULT VALUE STEP RANGE
USER
VALUE
Enable or disable the protocol
operation
Function DISABLED N/A [DISABLED – ENABLED]
Listening TCP port in the relay TCP Port 2404 N/A [0 : 65535]
Address in the ASDU header
Common Addr of
ASDU
255 N/A [0 : 65535]
Number of seconds for instantaneous
metering
Cyclic Meter Period 0 1 s [0 : 3600]
Synchronization Event Synchronization Event 0 0 N/A [0 : 3600]
1st Octect of IP address of 104 master
1
IEC104 NET1 CLI1
OCTET1
0 N/A [0 : 255]
2nd Octect of IP address of 104
master 1
IEC104 NET1 CLI1
OCTET2
0 N/A [0 : 255]
