2-20 F650 Digital Bay Controller GEK-113000AE
2.5 TECHNICAL SPECIFICATIONS 2 PRODUCT DESCRIPTION
2
2.5.2.9 PULSE COUNTERS
2.5.2.10 ANALOG COMPARATORS
Dropout level 97% to 98% of the pickup level
Level accuracy for primary magnitudes ±3% complete range.
Trip delay 0.00 to 900.00 s. in steps of 0.01 s.
Reset delay 0.00 to 900.00 s. in steps of 0.01 s.
Operate time 20 ms at 3 x Pickup at 50 Hz, typically
Timing accuracy ±3% of operate time or 50 ms. (whichever is greater)
Snapshot Events Selectable by setting
Number of Pulse counters available Up to 8
Multiplier factor 0.000 to 65000.000 in steps of 0.001
Overload factor 0 to 1000000 in steps of 1
Board Origin All available input/outputs boards in the device. See
ordering code [F, G, H, J]
Input origin up to 32 [depending on the board type selection]
Analog Input Any analog value available in the device
Analog Maximum Threshold value -100000.000 to 100000.000 in steps of 0.001
Analog Minimum Threshold value -100000.000 to 100000.000 in steps of 0.001
Analog Delay 0.00 to 900.00 in steps of 0.01
Analog Hysteresis 0.0 to 50.00 in steps of 0.1
Analog Direction (for activation inside or outside the
deadband)
IN or OUT
