Er r o r Co d es
SSD Error Name Error Set Condition Error Clear Conditions Error Response Action
000 No Error No Errors
001 Inlet Thermistor
Sh o r t
Inlet Thermistor’s
count of low readings
exceeds 10.
Inlet Thermistor’s count
of good readings exceeds
10.
Ru n H e a t Co n t r o l Fa l l b a c k
Algorit hm.
002 Outlet Thermistor
Sh o r t
Out let Th er mist or ’s
count of low readings
exceeds 10.
Out let Th er mist or ’s cou n t
of good readings exceeds
10.
Ru n H e a t Co n t r o l Fa l l b a c k
Algorit hm.
003 Inlet Thermistor
Open
Inlet Thermistor’s
count of high readings
exceeds 10.
Inlet Thermistor’s count
of good readings exceeds
10.
Ru n H e a t Co n t r o l
Fall b ack Algor it h m .
004 Outlet Thermistor
Open
Out let Th er mist or ’s
count of high readings
exceeds 10.
Out let Th er mist or ’s cou n t
of good readings exceeds
10.
Ru n H e a t Co n t r o l
Fall b ack Algor it h m .
005 EEPROM Error Bad CRC Detected
when reading a
page from EEPROM.
Er r o r c o n d i t i o n c l e a r s
when EEPROM checksum
is right .
006 Stuck Button Button depressed for 5
minutes.
When the button is re-
leased.
Cl ea r ed w h en st u c k b u t -
ton is released.
007 Miswire L2/N are miswired. Cleared when voltage
drops to Normal Levels.
L2 and N need to be re-
wired.
008 Door Switch Stuck 5 cycles are run and
the DOOR_LATCH_SIG-
NAL has not gone
open.
DOOR_LATCH_SIGNAL
goes to open.
009 Drum Motor Centrifugal Switch does
not change within a
certain period of time
after the Drum Motor
relay has been turned
RQRURȺ
Er r o r c o n d i t i o n w i l l n o t
clear until Main Control
board sees a change in
the centrifugal switch.
00d Door Signal Stuck 5 cycles are run and
the DOOR_STATE
signal in the hardware
Door Swit ch Detection
Ci r cu i t , h a s n o t go n e
RSHQIRU¿YHF\FOHV
Er r o r c o n d i t i o n w i l l n o t
clear until the Main Con-
trol Board sees the door
switch change.
Micro Blackout Recovery
to Run will not occur if this
error is set , and control
will go to pause.
