GE GFDR485EF User Manual

38
$LUÀRZ&RPSRQHQWV
Trap Duct
Grill Assembly
Inlet Ring
Fan Housing
Rear Duct
Exhaust Duct
Heater Assy
Gr i l l Assem bl y
Th e g r il l a ssem bl y c on sist o f a h ou sin g, l in t d oor
components, and a mounting surface for the lint
¿OWHUDQGVHQVRUURGV7KHVHQVRUURGVDQGIHOWVHDO
are separate parts.
Felt Seal
Sensor Rods
Gr i l l Assem bl y Rem ov a l
1. Disconnect power from the unit .
2. Remove the control panel.
3. Remove the front panel.
4. Disconnect the sensor harness connections.
5. Remove the three #2 Phillips screws located
inside the drum that hold the grill assembly in
place.
6. Pull assembly out of the front drum support.
Trap Duct
Tr ap Duct Rem ova l
1. Disconnect power from the unit .
2. Remove the control panel.
3. Remove the front panel.
4. Remove the four Phillips screws that hold secure
the trap duct.
#2 Phillips
#2 Phillips
#2 Phillips
#2 Phillips
5. 3XOOWKHWUDSGXFWRXWRIWKHLQOHWULQJ¿UVWWKHQ
pull the trap duct down to remove.
See Co n t r o l Pa n e l Rem o v a l o n p a g e 2 0 .
See Fr o n t Pa n e l Re m o v a l o n p a g e 2 4 .
See Co n t r o l Pa n e l Rem o v a l o n p a g e 2 0 .
See Fr o n t Pa n e l Re m o v a l o n p a g e 2 4 .

GE GFDR485EF Specifications

General

Brand	GE
Model	GFDR485EF
Type	Electric Dryer
Color	White
Voltage	240 V
Amperage	30 A
Drum Material	Aluminized Alloy
Number of Cycles	12
Number of Temperature Settings	5
Wrinkle Care Option	Yes
Moisture Sensor	Yes
Energy Star Certified	No
Control Type	Electronic
Venting Type	Vented
Width	27 in
