GE GFDR485EF - Drum Support, Belt, and Roller Systems

34
Incandescent Drum Lamp
Incandescent Drum Lamp Strip Circuit
N
L1
To B e l t Sw i t c h
and Steam Valve
High Limit
Th er m ost a t
Door Sw itch
Drum Lamp
To M CB J1 - 3
(Do or Sen se)
Te r m i n a l
Block
On Some Mod els
Oper at i ng Volt age: 120 VAC
Incandescent drum lamps are not present on all
models, some models have LED drum lamps.
Incandescent Drum Lamp Removal
1. Disconnect power from the unit .
2. Remove the control panel.
3. Remove the front panel.
4. Remove the front con-
trol assembly bracket assembly.
5. Remove the bulb, then squeeze the lamp mount-
ing clips and pull the lamp socket out through
the inside of the drum.
Fr on t Dr um Su pp or t
Front Drum Support Removal
1. Disconnect power from the unit .
2. 5HPRYHWKHOLQW¿OWHU
3. Remove the control panel.
4. Remove the front panel.
5. Remove the trap duct .
6. Remove the front con-
trol assembly bracket assembly.
7. Disconnect the wires connected to the front
drum support .
Harness Connector
8. Remove the four 1/4 in. hex screws that secure
the front drum support to the side panels.
9. Lift front drum support out of the key holes.
Bulb
Socket
See D r u m La m p Lo c a t i o n o n p a g e 17 .
See L ED D r u m La m p Sec t i o n o n p a g e 3 3.
See Co n t r o l Pa n e l Rem o v a l o n p a g e 2 0 .
See Fr o n t Pa n e l Re m o v a l o n p a g e 2 4 .
See Fr o n t Co n t r o l As s em b l y Br a c k et Rem o v a l
on page 25.
See Co n t r o l Pa n e l Rem o v a l o n p a g e 2 0 .
See Fr o n t Pa n e l Re m o v a l o n p a g e 2 4 .
See Tr a p D u c t Rem o v a l o n p a g e 38 .
See Fr o n t Co n t r o l As s em b l y Br a c k et Rem o v a l
on page 25.
