3.5.2 Performing leakage current testing
If ground testing is required for this system, verify that the ground testing results (see Table 3-3) are
< 0.1 Ohms before conducting leakage testing.
Leakage testing must be performed if the AC power plug has been replaced or disturbed.
The leakage current must not exceed 300 uA.
Before you begin, verify these steps:
1. Complete ground testing, if required (see 3.5.1 Performing ground resistance testing on
page 37).
2. Ensure that all system covers are installed.
3. Obtain a Dale 601/601E test meter or equivalent.
Perform leakage testing under the five specific conditions outlined in Table 3-4:
Table 3-4 Leakage current test conditions
Condition Power
Test meter
outlet
X-ray on Section reference
1 Off Normal No
3.5.2.1 Condition 1: Power off, normal outlet,
X-ray off
2 Off Reversed No
3.5.2.2 Condition 2: Power off, reversed
outlet, X-ray off
3 On Normal No
3.5.2.3 Condition 3: Power on, normal outlet,
X-ray off
4 On Reversed No
3.5.2.4 Condition 4: Power on, reversed
outlet, X-ray off
5 On Normal Yes
3.5.2.5 Condition 5: Power on, normal outlet,
X-ray on
