5. Keypads for user dialogue
6. Video station:
■
Hi–Brite monitor in a user area
■
VCR in option
1.8 AW workstation
2 monitors 19’’ flat panel and 1 monitor (flat panel) fixed on suspension (option) and 1 video
switcher. Check power input for switcher.
1.9 TV monitors
As basic configuration, two 21” (53 cm) (Hi–Brite) monitor are mounted on a TV monitor frame
support. In this case, the frame is fastened to a boom.
As an option 3 monitors, dual 21” (Hi–Brite) monitors and an additional monitoring screen are
supplied mounted on the TV frame support with tray. The frame is fastened to a boom.
Another option, in case of four 21” (Hi–Brite) monitors, is a fixed suspension. It’s the precabled
four monitor frame support.
For monitors, see Section 1.6
1.10 CENTRICITY CA1000 option
Refer to :
Centricity Cardiology CA 1000 V2.0 Preinstallation Guide
in the OEMs of the Innova
2100-IQ, 3100/3100-IQ, 4100/4100-IQ service manual.
1.11 Injectors
The recommended injectors are:
•
LF Angiomat Illumina (pedestal only)
•
Medrad Mark V + Provis (Table/rack mount or pedestal)
NOTE: Only the Medrad Mark V injector rack mounted version is authorized to be used on
Innova
IQ
Table
•
ACIST CVI (table rail mounted or Standard/cart)
•
Medrad Avanta (Pedestal only)
1.12 Fluoro UPS option
The Innova LC system can be protected with an optional Fluoro UPS.
There are two types of Fluoro UPS:
•
UL for North America and other 480V – 60Hz countries.
•
CE for Asia and Europe
Innova 2100-IQ, 3100/3100-IQ, 4100/4100-IQ Cardiovascular Imaging System Pre-Installation Manual
GE Healthcare Direction 5160944-13-1EN, Revision 2
32 1 Description of Innova System
