GE M60

5-52 M60 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL
PRODUCT SETUP CHAPTER 5: SETTINGS
5

DNP TCP/UDP PORT
NUMBER(20000): 20000
Range: 0 to 65535 in steps of 1

DNP UNSOL RESPONSE
FUNCTION: Disabled
Range: Enabled, Disabled

DNP UNSOL RESPONSE
TIMEOUT: 5 s
Range: 0 to 60 s in steps of 1

DNP UNSOL RESPONSE
MAX RETRIES: 10
Range: 1 to 255 in steps of 1

DNP UNSOL RESPONSE
DEST ADDRESS: 1
Range: 0 to 65519 in steps of 1

DNP CURRENT SCALE
FACTOR: 1
Range: 0.001, 0.01. 0.1, 1, 10, 100, 1000, 10000,
100000, 1000000, 10000000, 100000000

DNP VOLTAGE SCALE
FACTOR: 1
Range: 0.001, 0.01. 0.1, 1, 10, 100, 1000, 10000,
100000, 1000000, 10000000, 100000000

DNP POWER SCALE
FACTOR: 1
Range: 0.001, 0.01. 0.1, 1, 10, 100, 1000, 10000,
100000, 1000000, 10000000, 100000000

DNP ENERGY SCALE
FACTOR: 1
Range: 0.001, 0.01. 0.1, 1, 10, 100, 1000, 10000,
100000, 1000000, 10000000, 100000000

DNP PF SCALE
FACTOR: 1
Range: 0.001, 0.01. 0.1, 1, 10, 100, 1000, 10000,
100000, 1000000, 10000000, 100000000

DNP OTHER SCALE
FACTOR: 1
Range: 0.001, 0.01. 0.1, 1, 10, 100, 1000, 10000,
100000, 1000000, 10000000, 100000000

DNP CURRENT DEFAULT
DEADBAND: 30000
Range: 0 to 100000000 in steps of 1

DNP VOLTAGE DEFAULT
DEADBAND: 30000
Range: 0 to 100000000 in steps of 1

DNP POWER DEFAULT
DEADBAND: 30000
Range: 0 to 100000000 in steps of 1

DNP ENERGY DEFAULT
DEADBAND: 30000
Range: 0 to 100000000 in steps of 1

DNP PF DEFAULT
DEADBAND: 30000
Range: 0 to 100000000 in steps of 1

DNP OTHER DEFAULT
DEADBAND: 30000
Range: 0 to 100000000 in steps of 1

DNP TIME SYNC IIN
PERIOD: 1440 min
Range: 1 to 10080 min. in steps of 1

DNP MESSAGE FRAGMENT
SIZE: 240
Range: 30 to 2048 in steps of 1

DNP OBJECT 1
DEFAULT VARIATION: 2
Range: 1, 2

DNP OBJECT 2
DEFAULT VARIATION: 2
Range: 1, 2, 3

DNP OBJECT 20
DEFAULT VARIATION: 1
Range: 1, 2, 5, 6

DNP OBJECT 21
DEFAULT VARIATION: 1
Range: 1, 2, 9, 10

DNP OBJECT 22
DEFAULT VARIATION: 1
Range: 1, 2, 5, 6
