GE M60

CHAPTER 6: ACTUAL VALUES STATUS
M60 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL 6-5
6
6.3.3 Virtual inputs
ACTUAL VALUES  STATUS  VIRTUAL INPUTS
The present status of the 64 virtual inputs is shown here. The first line of a message display indicates the ID of the virtual
input. For example, ‘Virt Ip 1’ refers to the virtual input in terms of the default name. The second line of the display indicates
the logic state of the virtual input.
6.3.4 RxGOOSE boolean inputs
ACTUAL VALUES  STATUS  RxGOOSE BOOLEANS
6.3.5 RxGOOSE DPS inputs
ACTUAL VALUES  STATUS  RxGOOSE DPS
6.3.6 Teleprotection inputs
ACTUAL VALUES  STATUS  TELEPROTECTION INPUTS
 VIRTUAL INPUTS


Virt Ip 1
Off
Range: On, Off


Virt Ip 64
Off
Range: On, Off
 RxGOOSE BOOLEANS


RxGOOSE BOOLEAN 1
STATUS: Off
Range: On, Off


RxGOOSE BOOLEAN 256
STATUS: Off
Range: On, Off
The M60 is provided with optional IEC 61850 capability. This feature is specified as a software option at the
time of ordering. See the Order Codes section of chapter 2 for details.
 RxGOOSE DPS


RxGOOSE DPS 1
Status: Intermediate
Range: On, Off, Intermediate, Bad


RxGOOSE DPS 16
Status: Intermediate
Range: On, Off, Intermediate, Bad
The M60 is provided with optional IEC 61850 capability. This feature is specified as a software option at the
time of ordering. See the Order Codes section of chapter 2 for details.
 TELEPROTECTION
 INPUTS

TELEPROTECTION
INPUT 1-1: Off
Range: On, Off


TELEPROTECTION
INPUT 1-16: Off
Range: On, Off
