M60 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL A-1
M60 Motor Protection System
Appendix A: FlexAnalog operands
Appendices
FlexAnalog operands
This appendix outlines FlexAnalog parameters.
A.1 FlexAnalog items
A FlexAnalog parameter is an analog parameter.
FlexAnalog items are also viewable in a web browser. Enter the IP address of the UR, access the Device Information Menu
option, then the FlexAnalog Parameter Listing option. Entries displayed online depend on order code.
Table A-1: FlexAnalog data items
Address FlexAnalog name Units Description
5728 Stator Diff Iad Amps Stator differential phase A current (Iad)
5730 Stator Rest Iar Amps Stator restraint phase A current (Iar)
5732 Stator Diff Ibd Amps Stator differential phase B current (Ibd)
5734 Stator Rest Ibr Amps Stator restraint phase B current (Ibr)
5736 Stator Diff Icd Amps Stator differential phase C current (Icd)
5738 Stator Rest Icr Amps Stator restraint phase C current (Icr)
5740 Stator Diff CT Prim. Volts Stator differential CT primary
5760 Sns Dir Power 1 Watts Sensitive directional power 1 actual value
5762 Sns Dir Power 2 Watts Sensitive directional power 2 actual value
5824 Field RTD 1 Value --- Field RTD 1 value
5825 Field RTD 2 Value --- Field RTD 2 value
5826 Field RTD 3 Value --- Field RTD 3 value
5827 Field RTD 4 Value --- Field RTD 4 value
5828 Field RTD 5 Value --- Field RTD 5 value
5829 Field RTD 6 Value --- Field RTD 6 value
5830 Field RTD 7 Value --- Field RTD 7 value
5831 Field RTD 8 Value --- Field RTD 8 value
5832 Field TDR 1 Value --- Field TDR 1 value
5834 Field TDR 2 Value --- Field TDR 2 value
5836 Field TDR 3 Value --- Field TDR 3 value
5838 Field TDR 4 Value --- Field TDR 4 value
