GE M60

CHAPTER 5: SETTINGS CONTROL ELEMENTS
M60 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL 5-301
5
Figure 5-171: Digital counter logic
5.8.11 Monitoring elements
5.8.11.1 Menu
SETTINGS  CONTROL ELEMENTS  MONITORING ELEMENTS
 MONITORING
 ELEMENTS

 BREAKER 1
 ARCING CURRENT
See below

 BREAKER 2
 ARCING CURRENT

 BREAKER
 FLASHOVER 1
See page 5-305

 BREAKER
 FLASHOVER 2

 BREAKER RESTRIKE 1

See page 5-310

 BREAKER RESTRIKE 2


 CT FAILURE
 DETECTOR 1
See page 5-312


 CT FAILURE
 DETECTOR 4
