GE M60

6-10 M60 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL
STATUS CHAPTER 6: ACTUAL VALUES
6
6.3.17 Direct devices status
ACTUAL VALUES  STATUS  DIRECT DEVICES STATUS
These actual values represent the state of direct devices 1 through 16.
6.3.18 EGD protocol status
6.3.18.1 Fast exchange
ACTUAL VALUES  STATUS  EGD PROTOCOL STATUS  PRODUCER STATUS  FAST EXCHANGE 1
These values provide information for debugging an Ethernet Global Data (EGD) network. The EGD signature and packet size
for the fast EGD exchange display.
6.3.18.2 Slow exchange
ACTUAL VALUES  STATUS  EGD PROTOCOL STATUS  PRODUCER STATUS  SLOW EXCHANGE 1(2)
These values provide information for debugging an EGD network. The EGD signature and packet size for the slow EGD
exchanges display.
6.3.19 Teleprotection channel tests
ACTUAL VALUES  STATUS  TELEPROT CH TESTS
The status information for two channels is shown here.
 DIRECT DEVICES
 STATUS

DIRECT DEVICE 1
STATUS: Offline
Range: Offline, Online


DIRECT DEVICE 16
STATUS: Offline
Range: Offline, Online
 FAST EXCHANGE 1


FAST EXCHANGE 1
SIGNATURE: 0

FAST EXCHANGE 1
DATA LENGTH: 0
 SLOW EXCHANGE 1


SLOW EXCHANGE 1
SIGNATURE: 0

SLOW EXCHANGE 1
DATA LENGTH: 0
 TELEPROT CH TESTS


CHANNEL 1
STATUS: n/a
Range: n/a, FAIL, OK

CHANNEL 1 LOST
PACKETS: 1
Range: 1 to 65535 in steps of 1

CHANNEL 2
STATUS: n/a
Range: n/a, FAIL, OK

CHANNEL 2 LOST
PACKETS: 1
Range: 1 to 65535 in steps of 1

VALIDITY OF CHANNEL
CONFIGURATION: FAIL
Range: n/a, FAIL, OK
