GE M60

CHAPTER 6: ACTUAL VALUES FRONT PANEL
M60 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL 6-3
6
For status reporting, ‘On’ represents Logic 1 and ‘Off’ represents Logic 0.
6.2 Front panel
The front panel can be viewed and used in the EnerVista software, for example to view an error message displayed on the
front panel. The feature applies to the enhanced and standard front panels.
To view the front panel in EnerVista software:
1. Click Actual Values > Front Panel.
Figure 6-1: Front panel use in the software (C60 shown)
 ACTUAL VALUES
 RECORDS

 USER-PROGRAMMABLE
 FAULT REPORTS
See page 6-23

 STARTING RECORDS

See page 6-23

 MOTOR LEARNED
 DATA
See page 6-24

 EVENT RECORDS

See page 6-26

 OSCILLOGRAPHY

See page 6-27

 DATA LOGGER

See page 6-27

 MAINTENANCE

See page 6-28
 ACTUAL VALUES
 PRODUCT INFO

 MODEL INFORMATION

See page 6-29

 FIRMWARE REVISIONS

See page 6-29
