2-14 M60 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL
ORDER CODES CHAPTER 2: PRODUCT DESCRIPTION
2
Table 2-7: M60 order codes for reduced-size vertical units with process bus
M60 - * ** - * * * - F ** - H ** - M ** - P/R ** Reduced Size Vertical Mount (see note regarding P/R slot below)
BASE UNIT M60 | | | | | | | | | Base Unit
CPU T | | | | | | | | RS485 and Three Multi-mode fiber 100Base-FX (SFP with LC)
U | | | | | | | | RS485 and Two Multi-mode fiber 100Base-FX (SFP with LC), One 10/100Base-TX (SFP with RJ45)
V | | | | | | | | RS485 and Three 10/100Base-TX (SFP with RJ45)
SOFTWARE OPTIONS 00 | | | | | | | No Software Options
01 | | | | | | | Ethernet Global Data (EGD)
03 | | | | | | | IEC 61850
04 | | | | | | | Ethernet Global Data (EGD) and IEC 61850
28 | | | | | | | Broken rotor bar detection
29 | | | | | | | Broken rotor bar detection and Ethernet Global Data (EGD)
30 | | | | | | | Broken rotor bar detection and IEC 61850
31 | | | | | | | Broken rotor bar detection, Ethernet Global Data (EGD), and IEC 61850
A0 | | | | | | | CyberSentry Lvl 1
A1 | | | | | | | CyberSentry Lvl 1 and Ethernet Global Data (EGD)
A3 | | | | | | | CyberSentry Lvl 1 and IEC 61850
A4 | | | | | | | CyberSentry Lvl 1 and IEC 61850 and Ethernet Global Data (EGD)
AS | | | | | | | CyberSentry Lvl 1
AT | | | | | | | CyberSentry Lvl 1 and Ethernet Global Data (EGD)
AU | | | | | | | CyberSentry Lvl 1 and IEC 61850
AV | | | | | | | CyberSentry Lvl 1 and IEC 61850 and Ethernet Global Data (EGD)
B0 | | | | | | | CyberSentry Lvl 1 and Broken rotor bar detection
B1 | | | | | | | CyberSentry Lvl 1 and Broken rotor bar detection and Ethernet Global Data (EGD)
B3 | | | | | | | CyberSentry Lvl 1 and Broken rotor bar detection and IEC 61850
B4 | | | | | | | CyberSentry Lvl 1 and Broken rotor bar detection and IEC 61850 and Ethernet Global Data (EGD)
BS | | | | | | | IEEE 1588
BT | | | | | | | IEEE 1588 and Ethernet Global Data (EGD)
BU | | | | | | | IEEE 1588 and IEC 61850
BV | | | | | | | IEEE 1588 and IEC 61850 and Ethernet Global Data (EGD)
C0 | | | | | | | Parallel Redundancy Protocol (PRP)
C1 | | | | | | | PRP and Ethernet Global Data (EGD)
C3 | | | | | | | PRP and IEC 61850
C4 | | | | | | | PRP, Ethernet Global Data (EGD), and IEC 61850
CS | | | | | | | PRP and Rotor broken bar
CT | | | | | | | PRP, Rotor broken bar, and Ethernet Global Data (EGD)
CU | | | | | | | PRP, Rotor broken bar, and IEC 61850
CV | | | | | | | PRP, Rotor broken bar, Ethernet Global Data (EGD), and IEC 61850
D0 | | | | | | | IEEE 1588 and Broken rotor bar detection
D1 | | | | | | | IEEE 1588 and Broken rotor bar detection and Ethernet Global Data (EGD)
D3 | | | | | | | IEEE 1588 and Broken rotor bar detection and IEC 61850
D4 | | | | | | | IEEE 1588 and Broken rotor bar detection and IEC 61850 and Ethernet Global Data (EGD)
DS | | | | | | | IEEE 1588 and CyberSentry Lvl 1
DT | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and Ethernet Global Data (EGD)
DU | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and IEC 61850
DV | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and IEC 61850 and Ethernet Global Data (EGD)
E0 | | | | | | | IEEE 1588 and PRP
E1 | | | | | | | IEEE 1588, PRP, and Ethernet Global Data (EGD)
E3 | | | | | | | IEEE 1588, PRP, and IEC 61850
E4 | | | | | | | IEEE 1588, PRP, Ethernet Global Data (EGD), and IEC 61850
ES | | | | | | | IEEE 1588, PRP, and Rotor broken bar
ET | | | | | | | IEEE 1588, PRP, Rotor broken bar, and Ethernet Global Data (EGD)
EU | | | | | | | IEEE 1588, PRP, Rotor broken bar, and IEC 61850
EV | | | | | | | IEEE 1588, PRP, Rotor broken bar, Ethernet Global Data (EGD), and IEC 61850
F0 | | | | | | | PRP and CyberSentry Lvl 1
F1 | | | | | | | PRP, CyberSentry Lvl 1, and Ethernet Global Data (EGD)
F3 | | | | | | | PRP, CyberSentry Lvl 1, and IEC 61850
F4 | | | | | | | PRP, CyberSentry Lvl 1, Ethernet Global Date (EGD), and IEC 61850
FS | | | | | | | PRP, CyberSentry Lvl 1, and Rotor broken bar
FT | | | | | | | PRP, CyberSentry Lvl 1, Rotor broken bar, and Ethernet Global Data (EGD)
FU | | | | | | | PRP, CyberSentry Lvl 1, Rotor broken bar, and IEC 61850
FV | | | | | | | PRP, CyberSentry Lvl 1, Rotor broken bar, Ethernet Global Data (EGD), and IEC 61850
G0 | | | | | | | IEEE 1588, PRP, and CyberSentry Lvl 1
G1 | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, Ethernet Global Data (EGD)
G3 | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, and IEC 61850
G4 | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, Ethernet Global Data (EGD), and IEC 61850
GS | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, and Rotor broken bar
GT | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, Rotor broken bar, and Ethernet Global Data (EGD)
GU | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, Rotor broken bar, and IEC 61850
GV | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, Rotor broken bar, Ethernet Global Data (EGD), and IEC 61850
J0 | | | | | | | IEC 60870-5-103
J1 | | | | | | | IEC 60870-5-103 + EGD
J3 | | | | | | | IEC 60870-5-103 + IEC 61850
J4 | | | | | | | IEC 60870-5-103 + EGD + IEC 61850
JS | | | | | | | IEC 60870-5-103 + Rotor broken bar
JT | | | | | | | IEC 60870-5-103 + Rotor broken bar + EGD
JU | | | | | | | IEC 60870-5-103 + Rotor broken bar + IEC 61850
JV | | | | | | | IEC 60870-5-103 + Rotor broken bar + EGD + IEC 61850
K0 | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103
K1 | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103 + EGD
K3 | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103 + IEC 61850
K4 | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103 + EGD + IEC 61850
KS | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103 + Rotor broken bar
KT | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103 + Rotor broken bar + EGD
KU | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103 + Rotor broken bar + IEC 61850
KV | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103 + Rotor broken bar + EGD + IEC 61850
L0 | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1
L1 | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + EGD
L3 | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + IEC 61850
L4 | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + EGD + IEC 61850
LS | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + Rotor broken bar
LT | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + Rotor broken bar + EGD
LU | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + Rotor broken bar + IEC 61850
LV | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + Rotor broken bar + EGD + IEC 61850
MOUNT/COATING V | | | | | | Vertical (3/4 rack)
B | | | | | | Vertical (3/4 rack) with harsh environmental coating
FRONT PANEL + INTERFACE F | | | | | English display
D | | | | | French display
R | | | | | Russian display
A | | | | | Chinese display
K | | | | | Enhanced front panel with English display
M | | | | | Enhanced front panel with French display
Q | | | | | Enhanced front panel with Russian display
