CHAPTER 5: SETTINGS PRODUCT SETUP
M60 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL 5-105
5
The binary input points are sent as Class 1 data. They are sent either as a response to a general interrogation received
from the controller or reported spontaneously. Spontaneous transmission occurs as a response to cyclic Class 2 requests.
If the M60 wants to transmit Class 1 data at that time, it demands access for Class 1 data transmission (ACD=1 in the
control field of the response).
For any change to take effect, restart the relay.
SETTINGS  PRODUCT SETUP  COMMUNICATIONS  IEC 60870-5-103  IEC103 INPUTS MEASURANDS
 IEC103 INPUTS
 MEASURANDS

 ASDU 1

See below


 ASDU 4

 ASDU 1


ASDU 1 TYP:
9
Range: 3 or 9

ASDU 1 FUN:
0
Range: 0 to 255 in steps of 1

ASDU 1 INF:
0
Range: 0 to 255 in steps of 1

ASDU 1 SCAN TOUT:
0
Range: 0 to 1000 s in steps of 1

ASDU 1 ANALOG 1
Off
Range: FlexAnalog parameter

ASDU 1 ANALOG 1
FACTOR: 1.000
Range: 0.000 to 65.535 in steps of 0.001

ASDU 1 ANALOG 1
OFFSET: 0
Range: -32768 to 32767 in steps of 1


ASDU 1 ANALOG 9
Off
Range: FlexAnalog parameter

ASDU 1 ANALOG 9
FACTOR: 1.000
Range: 0.000 to 65.535 in steps of 0.001

ASDU 1 ANALOG 9
OFFSET: 0
Range: -32768 to 32767 in steps of 1

 ASDU 4


ASDU 4 TYP:
9
Range: 3 or 9

ASDU 4 FUN:
0
Range: 0 to 255 in steps of 1

ASDU 4 INF:
0
Range: 0 to 255 in steps of 1

ASDU 4 SCAN TOUT:
0
Range: 0 to 1000 s in steps of 1

ASDU 4 ANALOG 1
Off
Range: FlexAnalog parameter

ASDU 4 ANALOG 1
FACTOR: 1.000
Range: 0.000 to 65.535 in steps of 0.001
