6-8 MAC™ 3500 Resting ECG Analysis System Revision L
2021337-036
Parts Lists: Field Replaceable Units (FRUs)
Table 1. Upper Level Assembly Drawings
Item Part Number Item Description
1
PRINTER THERMAL MAC3500
(See “Universa
l Writer Kit, pn 2031810-002” on page 6-14 for more detailed information.)
2
BTN 3500 WRITER
(Not available as “stand-alone” FRU. See “MAC 3500 Plastics Kit, pn 2030898-001” o
n page 6-25)
3
LIGHT PIPE MAC3500
(Not available as “stand-alone” FRU. See “MAC 3500 Plastics Kit, pn 2030898-001” o
n page 6-25)
4
HLDR BUTTON MAC3500
(Not available as “stand-alone” FRU. See “MAC 3500 Plastics Kit, pn 2030898-001” o
n page 6-25)
5 419759-002 INSULATOR BD MAC SERIES
6 416298-001 BUTTON BATTERY MAC SERIES
7 419752-001 SPRING BATTERY MAC SERIES
8 419753-001 SPRING, BAT. BUTTON MAC
11
M3 X 8MM TORX SEMS
(Not available as “stand-alone” FRU. See “Hardware Kit for MAC 3500, pn 2030869-001” on page 6-24)
12 801222-002 PCB LED BOARD MAC 5000
13 700645-010 HARNESS PS/LED/MOTOR
14 421117-002 ASSY POWER SUPPLY MAC 5000
15 700686-001 HARNESS GROUND MAG MAC 5000
16 4520-004 WASHER FLAT SS #4,
17 420016-001 LABEL SET MAC5000 BOTTOM COVER
18 419755-002 PAD BOTTOM MAC SERIES
19 419957-001 CONN VERT MINI-DRAWER 14P
20 700682-001 HARNESS PWR TO CPU BD
21 801220-002 PCB MAC 5000 BATTERY TRANS
22 4550-014 WASH NYL .28 OD .12 ID .03THK
23
RAIL COMMUNICATION BOARD
(Not available as “stand-alone” FRU. See “MAC 3500 Plastics Kit, pn 2030898-001” o
n page 6-25)
24 801212-008
PCB ASSY MAC CPU ROHS
This board works on MAC 3500 and MAC 5500 devices running MA
C software versions 9D and 10B or later. It
does not work on MAC 5000 devices.
It is loaded with factory software that is not intended for patient use. If you are replacing a previous CPU, you
must
order an SD card with the appropriate software version; attempting to install earlier versions on a system with this
board will cause the system to fail.
Always reload the same or newer version of the software. Do not downgrade the
software to a lower version.
25 700687-002 CABLE ASSY PRTHD SNSR W/O FER
To Next Page
