Parts Lists: Field Replaceable Units (FRUs)
26
PLASTIC BRACKET, ACQ BOARD
(Not available as “stand-alone” FRU. See “MAC 3500 Plastics Kit, pn 2030898-001” o
n page 6-25)
27 2022328-002
PCB MAC3500 ACQUISITION BOARD V2
NOTE: This board is backwards compatible with MAC3500
s shipped with the Version 1 MAC3500 Acquisition
board, 2022328-001
28
PLASTIC CONNECTOR COVER
(Not available as “stand-alone” FRU. See “MAC 3500 Plastics Kit, pn 2030898-001” o
n page 6-25)
29 80177736 SCR FH #4-40X1/4" ZINC AHNL.DIN965
30
LABEL LUER MAC3500
(Not available as “stand-alone” FRU. See “MAC 3500 Plastics Kit, pn 2030898-001” o
n page 6-25)
31
CONNECTOR LUER FEMALE
(Not available as “stand-alone” FRU. See “MAC 3500 KISS P
ump Hardware Kit, pn 2030872-002” on page 6-29)
32
NUT LOCK
(Not available as “stand-alone” FRU. See “MAC 3500 KISS P
ump Hardware Kit, pn 2030872-002” on page 6-29)
33 82204620 TUBING PVC 3X1 GREY
34
PLUG LUER MALE
(Not available as “stand-alone” FRU. See “MAC 3500 KISS Pump Hardware Kit, pn 2030872-002” on page 6-29)
35
FLEX CKT ASSY CAM
(Not available as “stand-alone” FRU. See “Harness Kit for MAC 3500, pn 2030871-002” on page 6-28)
36
PANEL REAR MAC3500
(Not available as “stand-alone” FRU. See “MAC 3500 Plastics Kit, pn 2030898-001” o
n page 6-25)
37
PLASTIC TOP COVER
(Not available as “stand-alone” FRU. See “MAC 3500 Top
Cover Kit, pn 2030899-001” on page 6-27)
38
PLATE TOP COVER MAC3500
(Not available as “stand-alone” FRU. See “MAC 3500 Top
Cover Kit, pn 2030899-001” on page 6-27)
39
KYBD UNIVERSAL MAC3500
(Not available as “stand-alone” FRU. See “MAC 3500 Top
Cover Kit, pn 2030899-001” on page 6-27)
40
COVER KISS PUMP MAC3500
(Not available as “stand-alone” FRU. See “MAC 3500 Plastics Kit, pn 2030898-001” o
n page 6-25)
47
HARN LCD DISPLAY GROUND
(Not available as “stand-alone” FRU. See “Harness Kit for MAC 3500, pn 2030871-002” on page 6-28)
65 2026801-001 ASSY DISPLAY BEZEL MAC 3500
70
PLASTIC KEYBOARD BEZEL
(Not available as “stand-alone” FRU. See “MAC 3500 Plastics Kit, pn 2030898-001” o
n page 6-25)
72
LABEL CE/UL MAC3500
(Not available as “stand-alone” FRU. See “MAC 3500 Plastics Kit, pn 2030898-001” o
n page 6-25)
73
1
LABEL PRODUCT/SERIAL/MFG LOCATION SIZE A
74 * LABEL CLEAR OVERLAMINATE
Table 1. Upper Level Assembly Drawings (Continued)
Item
Part Number Item Description
