6-10 MAC™ 3500 Resting ECG Analysis System Revision L 
2021337-036
Parts Lists: Field Replaceable Units (FRUs)
75 * BAG POLY 22X22X47IN ANTI-STATIC
76 * PACKAGING CARTON 524 X 270 X 444.5
77 * LABEL CARTON MAC3500
78 * FILLER RH FOAM END CAP
79 * FILLER LH FOAM END CAP MAC3500
82
PANEL BLANK COMMUNICATION MAC3500
(Not available as “stand-alone” FRU. See “MAC 3500 Plastics Kit, pn 2030898-001” o
n page 6-25)
86 2026799-002
ASSY DISPLAY- MAC 3500 AUO LVDS-LED
(See “MAC 3500 Display Assembly, pn 2026799-002” on page 6-11 for more detailed information.)
87 2022882-002
PUMP KISS ASSY MAC 3500 
(See “MAC 3500 KISS Pump Assembly, pn 2022882-002” on page 6-13 for more detailed information.)
88
SPACER MALE/FEMALE M3 X 10 HEX
(Not available as “stand-alone” FRU. See “Hardware Kit for MAC 3500, pn 2030869-001” on page 6-24)
89
FITTING PNEU 1/8" QUICK FEMALE
(Not available as “stand-alone” FRU. See “MAC 3500 KISS P
ump Hardware Kit, pn 2030872-002” on page 6-29)
90
CLAMP CABLE 4.78MM ID BLK NYL
(Not available as “stand-alone” FRU. See “MAC 3500 KISS P
ump Hardware Kit, pn 2030872-002” on page 6-29)
91
SNAP RIVET NYLON .124 DIA
(Not available as “stand-alone” FRU. See “Hardware Kit for MAC 3500, pn 2030869-001” on page 6-24)
92
ADHESIVE BEZEL CORNER
(Not available as “stand-alone” FRU. See “MAC 3500 Plastics Kit, pn 2030898-001” o
n page 6-25)
93
FSTNR E-RING
(Not available as “stand-alone” FRU. See “Hardware Kit for MAC 3500, pn 2030869-001” on page 6-24)
94 * PACKAGING BOX ACCESSORIES MAC3500
95 2022332-004
PCB ASSY MAC5500 XM COMM BOARD ROHS
NOTE: 
This board is compatible with software version 9D and 10B or la
ter. When replacing an earlier board, you must
order an SD card with the appropriate software version. 
This board is compatible with CPU board 801212-008. It is not compatible with CPU boards 801212-00
7 or
801212-006.
96 900770-001 BATTERY PACK ASSY MAC PAC
98
2026831-007 PROGRAMMED SD CARD MAC V9D
2027268-005 SD card for external storage (2 GB)
2027268-004 SD card for external storage (512 MB)
2027268-003 SD card for external storage (256 MB)
2027268-002 SD card for external storage (128 MB)
1 Part not available as a stand-alone FRU. This part is only available as part of the entire assembly.
Table 1. Upper Level Assembly Drawings (Continued)
Item
Part Number Item Description
