6. Control Functions and Parameter Settings
6-24
Block-C parameters (Basic function constants) list
ApplicationNo. Parameter Unit Default Min. Max. Function
ST V/f VEC PM
C09 – Parameter protection/operation locks
4 Reverse run jogging
(sequence R JOG)
lock
1. 1. 2. Set this to prevent unintentional
reverse jogging operation.
When set to “2”, the “R·JOG”
operation command will be disabled.
Note that if the reverse run setting
(negative value) is input into the
jogging setting during “F·JOG”
operation, reverse run will start.
= 1 : Enable = 2 : Lock

5 Reverse run during
ACR mode lock
1. 1. 2.
Set this to prevent unintentional
reverse run operation.
When set to “2”, reverse run during
ACR operation will be cancel.
The reverse run speed will be limited
to approx. 1% if reverse run is started.
This setting is ignored in the V/f
mode.
= 1 : Enable
= 2 : Lock

6 Fault history buffer
clear
0. 0 9999 Set 1 for the setting value to clear the
fault history details.
The clearing operation will not take
place at a setting other than 1.
1: Clear fault history

7 Default value load 0. 0 9999 9: All default values load (excluding
maintenance)
10: Parameter A
11: Parameters B, C basic functions
12: Parameters B, C extended
functions
13: Parameter B software option
function
Parameter C hardware option
function
14: Parameters B basic functions
15: Parameters B extended functions
16: Parameter B software option
function
17: Parameters C basic functions
18: Parameters C extended functions
19: Parameter C hardware option
function

C10 – Custom parameter register
1.99.9 1.00.0 2.99.90
1
2
3
4
5
6
7
Custom– 0
– 1
– 2
– 3
– 4
– 5
– 6
– 7
Parameter
number
Block number
0: Block B
1: Block C
Set for each parameter No. to be
displayed and changed as an A04-0
to 7 custom parameter.
Example)
To set B13-0
(torque
setting), set as 1.13.0.

