GE Voluson P8 - Section 8-14 Replacement of the NEST; 8-14-1 Manpower; 8-14-2 Tools; 8-14-3 Preparations

GE HEALTHCAREDRAFT VOLUSON® P8 / VOLUSON® P6
DIRECTION 5459672-100, R
EVISION 6 DRAFT (JANUARY 17, 2013) PROPRIETARY SERVICE MANUAL
Chapter 8 - Replacement Procedures 8-33
Section 8-14
Replacement of the NEST
8-14-1 Manpower
One person, 10 minutes
8-14-2 Tools
Philips screwdriver, Allen Wrench
8-14-3 Preparations
1.) Power Off/Shutdown the system as described in 4-3-2 on page 4-4.
8-14-4 Removal Procedure
1.) Follow the Replacement procedure of section 8-11-4 (step 13 ~ 19).
2.) Disconnect 2 connectors. (DVD SATA CABLE, DVD POWER CABLE). Refer to the Figure 8-38
below.
Figure 8-38 Cable Connection
