GE HEALTHCARERAFT VOLUSON® P8 / VOLUSON® P6

DIRECTION 5459672-100, R

EVISION 6 DRAFT (JANUARY 17, 2013) PROPRIETARY SERVICE MANUAL

9-18 Section 9-12 - Probes

9-12-4 2D-Probes - Phased Array Transducers

Figure 9-11 2D Phased Array Probe

Table 9-15 2D-Probes - Phased Array Transducers

Item Part Name Part Number Description Qty CRU FRU

807 3Sc-RS

47237516

(H45041DL)

Broadband phased array

transducer, 1.45-4.2 MHz, 64

Elements Applications:

Cardiology, Pediatrics, Neurology

111

807
