GE HEALTHCAREDRAFT VOLUSON® P8 / VOLUSON® P6

DIRECTION 5459672-100, R

EVISION 6 DRAFT (JANUARY 17, 2013) PROPRIETARY SERVICE MANUAL

Chapter 9 - Renewal Parts 9-5

Section 9-5

LCD Monitor

Figure 9-2 LCD Monitor

Table 9-4 LCD Monitor

Item Part Name Part Number Description Qty CRU FRU

201

15" LCD Monitor

5439256

15" LCD Monitor

201
