8-106 Section 8-44 - Replacement of CWD

Section 8-44

Replacement of CWD

8-44-1 Manpower

One person, 30 minutes.

8-44-2 Tools

Philips screwdriver, Hirose ejector

8-44-3 Preparations

Power Off/Shutdown the system as described in 4-3-2 on page 4-4.

8-44-4 Removal Procedure

1.) Unscrew 2 screws and remove POWER CORD FIX BRKT and power cord.

Figure 8-134 Power Bracket

Power Cord bracket

Power Cord
