GE HEALTHCARERAFT VOLUSON® P8 / VOLUSON® P6

DIRECTION 5459672-100, R

EVISION 6 DRAFT (JANUARY 17, 2013) PROPRIETARY SERVICE MANUAL

9-16 Section 9-12 - Probes

9-12-2 2D-Probes - Linear Array Transducer

Figure 9-9 2D Linear Array Transducer

Table 9-13 2D linear array Transducers

Item Part Name Part Number Description Qty CRU FRU

803 12L-RS 5154514

Small and lightweight linear-array transducer 4.0 - 10.0 MHz, 192

Elements Applications: Small parts, Peripheral vascular, Pediatrics,

Orthopedics

-1 1

803
