ADP200 Application PID-IMM User Manual Pag. 17 of 80
4 Commissioning via GF_eXpress
4.1 General description
This section describes a standard application commissioning procedure using a PC with Gefran GF-eXpress
configurator.
The startup with a PC require Gefran GF-eXpress version 1.9.15 or higher and Catalog 2.38.0 or higher
installed, the RS485 - PCI COM connection kit to the drive and the CD to install the Application.
The CD to install the application contains a wizard (automatic procedure) that copies the necessary files to the
folders of the GF-eXpress catalog. The setup files can be download from Gefran web page
http://www.gefran.com/en/gb
in the download area.
In factory configuration ADP200 - PID-IMM application is in Application 1 that is Enabled (Menu DRIVE
CONFIG Parameter IPA558 Application Select = 1 in expert mode).
When you connect the PC to the Modbus serial port of the drive and open GF-eXpress, you will find and open
this file:
If you press select you open ADP200 Fw2.0.0 with PID_IMM application FW. 1.20.37.3.
