10 ADV200 WA • Quick start up guide - Specification and installation
Solid State Motor Overload Protection
Drive incorporate motor overload protection. Protection is implemented as
software function. Instruction manual specify degree of protection and detailed
installation instruction. *
*Applicable up to 9 May 2013.
New requirement. Applicable as from 9 May 2013.
The drive is not provided with the internal motor overload protection (software
function) as required under UL 508c as from 9 May 2013.
The drive is designed for use with motors with integrated thermal overload protec-
tion.
The integrated thermal overload protection signal must be connected to the equip-
ment, starting from a contact, on the “digital input connector” terminal, pins 4 and
10, that accepts a maximum of 24 VDC, 5 mA. The nal result of this signal is the
switching of the motor control device output to solid state OFF.
