ADV200 WA • Quick start up guide - Specification and installation 121
10.2.2 Input chokes for conformity to EN61000-3-12 for drives with input cur-
rents of between 16A and 75A
Sizes
Lac Code Value [μH]
2110
LHC-2110-WA
S7HB3 1750
2150
LHC-2150-WA S7HB0 1300
3185 LHC-3185-WA S7HB4 1100
3220 LHC-3220-WA S7HB5 880
3300
LHC-3300-WA S7HB6 660
4370 - 4450 LHC-4450-WA
S7HB7 520
With this combination the maximum output voltage falls to Vout = 0.94 Vin.
There are no limitations for inverter sizes with output current ≤16A as these are
considered to be for professional use.
The applicable standard for inverters with output currents of more than 75 A is
EN61000-3-4.
