122 ADV200 WA • Quick start up guide - Specification and installation
10.2.3 Optional external choke (L2)
The ADV200 WA drive can be used with general purpose standard motors or with
motors specially designed for drive use. The latter usually have a higher isolation
rating to better withstand PWM voltage.
Examples of reference regulations are provided below:
Motors designed for use with Adjustable Frequency Drives do not require any spe-
cic ltering of the voltage waveform from the drive. For general purpose motors,
especially with long cable runs (typically over 100 m [328 feet]) an output choke is
recommended to mantain the voltage waveform within the specied limits.
The rated current of the chokes should be approx. 20% above the rated current
of the frequency drive in order to take into account additional losses due to PWM
waveform.
Sizes 1015 ... 74000
Sizes
Inverter
output
Mains
inductance
(mH)
Rated
current
(A)
Saturation
current
(A)
Type Code
1015 ... 1055
HD 1.4 9.5 20 LU3-003 S7FG2
LD 0.87 16 34 LU3-005 S7FG3
2075
HD 0.87 16 34 LU3-005 S7FG3
LD 0.51 27 57 LU3-011 S7FG4
2110 - 2150
HD 0.51 27 57 LU3-011 S7FG4
LD 0.43 32 68 LU3-015 S7FH2
3185
HD 0.43 32 68 LU3-015 S7FH2
LD 0.33 42 72 LU3-022 S7FH3
3220
HD 0.33 42 72 LU3-022 S7FH3
LD 0.23 58 100 LU3-030 S7FH4
3300
HD 0.23 58 100 LU3-030 S7FH4
LD 0.24 58 100 LU3-030 S7FH4
4370
HD 0.24 58 100 LU3-030 S7FH4
LD 0.18 76 130 LU3-037 S7FH5
4450
HD 0.18 76 130 LU3-037 S7FH5
LD 0.12 120 205 LU3-055 S7FH6
4550
HD 0.12 120 205 LU3-090 S7F10
LD 0.07 180 310 LU3-090 S7F10
5750 - 5900 HD / LD 0.07 180 310 LU3-090 S7F10
51100
HD 0.07 180 310 LU3-090 S7F10
LD 0.041 310 540 LU3-160 S7FH8
61320 - 61600 HD / LD 0.041 310 540 LU3-160 S7FH8
72000
HD 0.041 310 540 LU3-160 S7FH8
LD 0.03 400 770 LU3-200 S7AF0
72500
HD 0.03 400 770 LU3-200 S7AF0
LD 0.022 580 1100 LU3-315 S7FH9
73150 HD / LD 0.022 580 1100 LU3-315 S7FH9
73550 - 74000 HD / LD 0.015 730 1240 LU3-400 S7FO8
Note ! When the drive is operated at the rated current and at 50 Hz, the output chokes cause a voltage drop
of approx. 2% of the output voltage.
Chokes dimensions and weights are listed in the Gefran Accessories catalogue (1S9I09).
