14 ADV200 WA • Quick start up guide - Specification and installation
The inverter must be selected according to the rated current of the motor.
The rated output current of the drive must be higher than or equal to the rated cur-
rent of the motor used.
The speed of the three-phase motor is determined by the number of pole pairs and
the frequency (nameplate, data sheet) of the motor concerned.
Operation above the rated frequency and speed of the motor must take into ac-
count the specications given by the manufacturer losses (bearings, unbalance
etc.). This also applies to temperature specications for continuous operation under
20 Hz (poor motor ventilation, not applicable to motors with external ventilation).
2.1.1 Parallel inverters
• Inverters of between 500 kW and 800 kW comprise one master and one
slave.
• Inverters of over 1000 kW comprise one master and two slaves.
When placing your order please give the code number of the master and slave
and number of these:
Power code Description (Designation) code Description (Designation)
500kW
S9O25WM ADV200-WA-72500-KXX-4-MS 05 -SI S9O25WMC ADV200-WA-72500-KXX-4- MS 05-DC- SI
S9O25WS ADV200-WA-72500-XXX-4-SL S9O25SWMC ADV200-WA-72500-KXX-4- SL-DC
630kW
S9O26WM ADV200-WA-73150-KXX-4-MS 06 -SI S9O26WMC ADV200-WA-73150-KXX-4-MS 06-DC-SI
S9O26WS ADV200-WA-73150-XXX-4-SL S9O26WSC ADV200-WA-73150-KXX-4-SL-DC
710kW
S9O27WM ADV200-WA-73550-KXX-4-MS 07 -SI S9O27WMC ADV200-WA-73550-KXX-4-MS 07-DC-SI
S9O27WS ADV200-WA-73550-XXX-4-SL S9O27WSC ADV200-WA-73550-KXX-4-SL-DC
800kW
S9O28WM ADV200-WA-74000-KXX-4-MS 08 -SI S9O28WMC ADV200-WA-74000-KXX-4- MS 08-DC-SI
S9O28WS ADV200-WA-74000-XXX-4-SL S9O28WSC ADV200-WA-74000-KXX-4- SL-DC
1000kW
S9O27WM1 ADV200-WA-73550-KXX-4-MS 10 -SI S9O27WM2 ADV200-WA-73550-KXX-4-MS 10-DC-SI
S9O27WS ADV200-WA-73550-XXX-4-SL S9O27WSC ADV200-WA-73550-KXX-4-SL-DC
S9O27WS ADV200-WA-73550-XXX-4-SL S9O27WSC ADV200-WA-73550-KXX-4-SL-DC
1200kW
S9O28WM1 ADV200-WA-74000-KXX-4-MS 12 -SI S9O28WM2 ADV200-WA-74000-KXX-4- MS 12-DC-SI
S9O28WS ADV200-WA-74000-XXX-4-SL S9O28WSC ADV200-WA-74000-KXX-4- SL-DC
S9O28WS ADV200-WA-74000-XXX-4-SL S9O28WSC ADV200-WA-74000-KXX-4- SL-DC
710kW
S9O29WM ADV200-WA-73550-KXX-4A-MS 07-SI S9O29WMC ADV200-WA-73550-KXX-4A-MS 07-DC-SI
S9O29WS ADV200-WA-73550-KXX-4A -SL S9O29WSC ADV200-WA-73550-KXX-4A -SL-DC
800kW
S9O30WM ADV200-WA-74000-KXX-4A- MS 08-SI S9O30WMC ADV200-WA-74000-KXX-4A- MS 08-DC-SI
S9O30WS ADV200-WA-74000-KXX-4A- SL S9O30WSC ADV200-WA-74000-KXX-4A- SL-DC
1000kW
S9O29WM1 ADV200-WA-73550-KXX-4A-MS 10-SI S9O29WM2 ADV200-WA-73550-KXX-4A-MS 10-DC-SI
S9O29WS ADV200-WA-73550-KXX-4A -SL S9O29WSC ADV200-WA-73550-KXX-4A -SL-DC
S9O29WS ADV200-WA-73550-KXX-4A -SL S9O29WSC ADV200-WA-73550-KXX-4A -SL-DC
1200kW
S9O30WM1 ADV200-WA-74000-KXX-4A- MS 12-SI S9O30WM2 ADV200-WA-74000-KXX-4A- MS 12-DC-SI
S9O30WS ADV200-WA-74000-KXX-4A- SL S9O30WSC ADV200-WA-74000-KXX-4A- SL-DC
S9O30WS ADV200-WA-74000-KXX-4A- SL S9O30WSC ADV200-WA-74000-KXX-4A- SL-DC
