gefran ADV200 WA DC Series User Manual

30 ADV200 WA • Quick start up guide - Specification and installation
5.1.4 Block diagram power section
ADV200 WA-1015 ... 61600
L1
L2
L3
C
D
BR2 (*)
BR1 (*)
L
DC
U
V
W
R
PRECHARGE
B
RAKING
IGBT (
OPT
.)
ADV200 WA-3220-DC... 61600-DC
C
D
U
V
W
CDC LINK
450 - 750 Vdc
ADV200 WA-72000 ... 74000
L1
L2
L3
C
D
U
V
W
500 ... 800kW
L1
L2
L3
C
D
U
V
W
ADV- ...- MS..
L1
L2
L3
C
D
U
V
W
LINE
380-500Vac, 3ph
Input
fuse
Input choke
(mandatory)
Input
fuse
Input choke
(mandatory)
ADV- ...- SL..
Output choke
(mandatory)
Output choke
(mandatory)
U
V
W
To motor
