ADV200 WA • Quick start up guide - Specification and installation 31
500 ... 800kW (ADV200 WA-...-DC)
C
D
U
V
W
ADV- ...- MS..-4-DC
C
D
U
V
W
450 - 750 Vdc
Input
fuse
Input
fuse
ADV- ...- SL..-4-DC
Output choke
(mandatory)
Output choke
(mandatory)
U
V
W
To motor
1000 ... 1200kW
L1
L2
L3
C
D
U
V
W
ADV- ...- MS..
L1
L2
L3
C
D
U
V
W
LINE
380-500Vac, 3ph
Input
fuse
Input choke
(mandatory)
Input
fuse
Input choke
(mandatory)
ADV- ...- SL..
Output choke
(mandatory)
Output choke
(mandatory)
U
V
W
To motor
L1
L2
L3
C
D
U
V
W
Input
fuse
Input choke
(mandatory)
ADV- ...- SL..
Output choke
(mandatory)
1000 ... 1200kW (ADV200 WA-...-DC)
C
D
U
V
W
ADV- ...- MS..-4-DC
C
D
U
V
W
Input
fuse
Input
fuse
ADV- ...- SL..-4-DC
Output choke
(mandatory)
Output choke
(mandatory)
U
V
W
To motor
C
D
U
V
W
Input
fuse
ADV- ...- SL..-4-DC
Output choke
(mandatory)
450 - 750 Vdc
(*) Terminals BR1/BR2 are standard up to size ADV200 WA-3300, optional in sizes ADV200 WA-4370 ...
5750, larger sizes are not used. These are not present in ADV200 WA-...-DC versions.
