ADV200 WA • Quick start up guide - Specification and installation 37
5.1.8 Motor connection
ADV200 WA-1015 ... 61600
M
3 ph
L1 L2 L3 BR1 BR2 C D U V W
Note: terminals L1-L2 and L3 are not present in -DC versions.
ADV200 WA-72000 ... 74000
L1 L2 L3 U V W
M
3 ph
Note: terminals L1-L2 and L3 are not present in -DC versions.
500 ... 800 kW
L1 L2 L3 U V W
M
3 ph
L1 L2 L3 U V W
ADV-...-MS-.. ADV-...-SL
Output choke
or current-sharing
choke (mandatory)
Output choke
or current-sharing
choke (mandatory)
Note: terminals L1-L2 and L3 are not present in -DC versions.
