9 - Specication
9.1 Environmental Conditions
Installation location ������������������Pollution degree 2 or lower (free from direct sunligth, vi-
bration, dust, corrosive or inflammable gases, fog, vapour
oil and dripped water, avoid saline environment)
Installation altitude ������������������Max 2000m (6562 feet) above sea level;.
Mechanical conditions for installation ���Vibrational stress: EN 60721-3-3 Class 3M1
Operating temperature ��������������-10…+40°C (32°…104°F)
Operating temperature (1) ������������+40 ... +50°C with derating, (+104 … +122°F with
derating)
Air humidity (operating) ��������������5 % to 85 % and 1 g/m
3
to 25 g/m
3
without moisture
condensation or icing (class 3K3 as per EN50178)
Air pressure (operating) [kPa] ����������86 to 106 (class 3K3 as per EN50178)
(1) In menu 4 - DRIVE CONFIG set the Ambient temperature parameter, PAR 564, to 1 (50°C).
10 % derating of output current.
The drive is suitable for use under the environmental service conditions (climate,
mechanical, pollution, etc.) dened as usual service conditions according to
EN61800-2.
9.2 Standards
Climatic conditions ������������������EN 60721-3-3
Electrical safety ��������������������EN 50178, EN 61800-5-1, UL508C, UL840 degree of
pollution 2
Vibration ��������������������������EN 60068-2-6, test Fc.
EMC compatibility �������������������EN61800-3
Protection degree �������������������IP20, ≥ size 7: IP00
Approvals ������������������������� ,
LL
9.3 Accuracy (Asyncronous)
9.3.1 Current control
Type ������������������������������FOC OL (open loop Field Oriented Control)
Loop sampling time �������������������125µs
Response time ����������������������600 - 1600µs
PWM frequency ���������������������2, 4, 6, 8, 10, 12 kHz (size dependent)
9.3.2 Speed control
Type ������������������������������FOC OL (open loop Field Oriented Control)
Loop sampling time �������������������125µs
Response time ����������������������5 - 10ms
Speed measurement ������������������FP, F mode
Speed regulation accuracy �������������FOC open loop : ± 30 % rated slip
V/F : ± 60 % rated slip.
9.3.3 Speed control limits
Control range (1) ���������������������± 32000 rpm
Attention
