108 ADV200 WA • Quick start up guide - Specification and installation
9.9 Weight and dimensions
Sizes
ADV200 WA-...-4
Weight (kg) Weight (lbs) Sizes
ADV200 WA-...-4-DC
Weight (kg) Weight (lbs)
1015 ... 1055 5,8 12,8 - - -
2075 ... 2150 10,2 22,5 - - -
3185 ... 3220 16,4 36,2 3220 12 26,5
3300 22 48,5 3300 18 39,7
4370 ... 4550 32 70,6 4370 ... 4550 24 52,9
5750 ... 51100 60 132 5750 ... 51100 40 88,2
61320 ... 61600 90 198 61320 ... 61600 68 150
72000 ... 72500 130 287 72000 ... 72500 120 264.5
73150 140 309 73150 130 286.6
73550 ... 74000 150 331 73550 ... 74000 140 308.6
500 kW 260 573 500 kW 240 529
630 kW 280 617 630 kW 260 573
710 ... 800 kW 300 661 710 ... 800 kW 420 617
1000 ... 1200 kW 450 992 1000 ... 1200 kW 420 926
Note ! Weights referred to standard drive with keypad, without options, packaging not included.
