gefran ADV200 WA DC Series User Manual

ADV200 WA • Quick start up guide - Specification and installation 109
118 mm (4.65”)
82 mm (3.23”)
290 mm
(11.42”)
235 mm
(9.25”)
59 mm
(2.32”)
307 mm
(12.09”)
384 mm
(15.12”)
322 mm
(12.68”)
100 [3.94”]
306.4 [12.06”]
Figure 9.10.1: Size 1 Dimensions
150 mm (5.91”)
110 mm (4.33”)
360 mm
(14.17”)
250 mm
(9.84”)
70 mm
(2.76”)
377 mm
(14.84”)
392 mm
(15.43”)
440 mm
(17.32”)
120 [4.72”]
376.6 [14.83”]
Figure 9.10.2: Size 2 dimensions

gefran ADV200 WA DC Series Specifications

General

Brand	gefran
Model	ADV200 WA DC Series
Category	DC Drives
Language	English
