ADV200 WA • Quick start up guide - Specification and installation 117

10 - Options

10.1 Optional external fuses

10.1.1 AC input side fuses (F1)

The inverter must be fused on the AC Input side.

Use fast fuses only.

Sizes

F1 - AC input side fuses

DC link

capacitors

life time [h]

EUROPE AMERICA

Type Code Type Code

1015 ... 1030 50000 GRD2/10 F4D13 A70P10 S7G49

1040 50000 GRD2/10 F4D13 A70P10 S7G49

1055 ... 2075 50000 GRD2/16 F4D14 A70P20-1 S7G48

2110 50000 GRD2/25 F4D16 A70P40 S7G52

2150 50000 GRD3/35 F4D20 A70P40 S7G52

3185 - 3220 50000 GRD3/50 F4D21 A70P50 S7G53

3300 - 4370 50000 S00C+/üf1/80/80A/690V F4EAF A70P80 S7G54

4450 50000 S00C+/üf1/80/100A/690V F4G18 A70P100 S7G55

4550

50000 S00C+/üf1/80/125A/690V F4EAJ A70P150 S7G56

5750 - 5900 50000 S00/üf1/80/200A/690V F4G23 A70P200 S7G58

51100

50000 S1üf1/110/250A/690V F4G28 A70P250 S7G59

61320 50000 S1üf1/110/315A/690V F4G30 A70P350 S7G61

61600 50000 S2üf1/110/400A/690V F4G34 A70P400 S7G62

72000 50000 S2üf1/110/500A/690V F4E30 A70P500 S7G63

72500 - 73150 50000 S2üf1/110/630A/690V F4E31 A70P600 S7G65

73550 - 74000 50000 S2üf1/110/800A/690V F4G87 A70P800 S7813

500 kW

ADV200-WA-72500-KXX-4-MS 05 -SI

50000

S2üf1/110/630A/690V

F4E31 A70P600 S7G65

ADV200-WA-72500-XXX-4-SL

50000

S2üf1/110/630A/690V

F4E31 A70P600 S7G65

630 kW

ADV200-WA-73150-KXX-4-MS 06 -SI

50000 S2üf1/110/630A/690V F4E31 A70P600 S7G65

ADV200-WA-73150-XXX-4-SL

50000 S2üf1/110/630A/690V F4E31 A70P600 S7G65

710 kW

ADV200-WA-73550-KXX-4-MS 07 -SI
