ADV200 WA • Quick start up guide - Specification and installation 123
Sizes 500 ... 1200 kW
The use of output chokes is mandatory for these sizes; as a function of the application/connection,
according to the following criteria:
• for applications with short motor cables (≤ 100 m long) bus bars with an integrated choke (see
Table 2) or single distributor chokes may be used (see Table 1);
• for applications with long motor cables (> 100 m long) bus bars with an integrated choke (see
Table 2) plus the output choke (see Table 3) or single distributor chokes may be used (see Table 1);
Table 1: Current distributor output choke
Sizes
Inverter
output
Mains
inductance
(μH)
Rated
current
(A)
Saturation
current
(A)
Type Code
500 kW
ADV200-WA-72500-KXX-4-MS 05 -SI
HD / LD
7.5 450 675 LU3-4-500 S7FFI2
ADV200-WA-72500-XXX-4-SL
7.5 450 675 LU3-4-500 S7FFI2
630 kW
ADV200-WA-73150-KXX-4-MS 06 -SI
HD
7.5 450 675 LU3-4-500 S7FFI2
ADV200-WA-73150-XXX-4-SL
7.5 450 675 LU3-4-500 S7FFI2
630 kW
ADV200-WA-73150-KXX-4-MS 06 -SI
LD
5.0 730 975 LU3-4-800 S7FFI1
ADV200-WA-73150-XXX-4-SL
5.0 730 975 LU3-4-800 S7FFI1
710 kW
ADV200-WA-73550-KXX-4-MS 07 -SI
HD / LD
5.0 730 975 LU3-4-800 S7FFI1
ADV200-WA-73550-XXX-4-SL
5.0 730 975 LU3-4-800 S7FFI1
800 kW
ADV200-WA-74000-KXX-4-MS 08 -SI
HD / LD
5.0 730 975 LU3-4-800 S7FFI1
ADV200-WA-74000-XXX-4-SL
5.0 730 975 LU3-4-800 S7FFI1
1000 kW
ADV200-WA-73550-KXX-4-MS 10 -SI
HD / LD
5.0 730 975 LU3-4-800 S7FFI1
ADV200-WA-73550-XXX-4-SL
5.0 730 975 LU3-4-800 S7FFI1
ADV200-WA-73550-XXX-4-SL
5.0 730 975 LU3-4-800 S7FFI1
1200 kW
ADV200-WA-74000-KXX-4-MS 12 -SI
HD / LD
5.0 730 975 LU3-4-800 S7FFI1
ADV200-WA-74000-XXX-4-SL
5.0 730 975 LU3-4-800 S7FFI1
ADV200-WA-74000-XXX-4-SL
5.0 730 975 LU3-4-800 S7FFI1
Note ! Chokes dimensions and weights are listed in the Gefran Accessories catalogue (1S9I09).
