ADV200 WA • Quick start up guide - Specification and installation 125
Table 3: Chokes for long cables
Sizes
Inverter
output
Mains
inductance
(mH)
Rated
current
(A)
Saturation
current
(A)
Type Code
500 kW
ADV200-WA-72500-KXX-4-MS 05 -SI
HD
0.03 400 770 LU3-200 S7AF0
ADV200-WA-72500-XXX-4-SL
0.03 400 770 LU3-200 S7AF0
500 kW
ADV200-WA-72500-KXX-4-MS 05 -SI
LD
0.022 580 1100 LU3-315 S7FH9
ADV200-WA-72500-XXX-4-SL
0.022 580 1100 LU3-315 S7FH9
630 kW
ADV200-WA-73150-KXX-4-MS 06 -SI
HD / LD
0.015 730 1240 LU3-400 S7FO8
ADV200-WA-73150-XXX-4-SL
0.015 730 1240 LU3-400 S7FO8
710 kW
ADV200-WA-73550-KXX-4-MS 07 -SI
HD / LD
0.015 730 1240 LU3-400 S7FO8
ADV200-WA-73550-XXX-4-SL
0.015 730 1240 LU3-400 S7FO8
800 kW
ADV200-WA-74000-KXX-4-MS 08 -SI
HD / LD
0.015 730 1240 LU3-400 S7FO8
ADV200-WA-74000-XXX-4-SL
0.015 730 1240 LU3-400 S7FO8
1000 kW
ADV200-WA-73550-KXX-4-MS 10 -SI
HD / LD
0.015 730 1240 LU3-400 S7FO8
ADV200-WA-73550-XXX-4-SL
0.015 730 1240 LU3-400 S7FO8
ADV200-WA-73550-XXX-4-SL
0.015 730 1240 LU3-400 S7FO8
1200 kW
ADV200-WA-74000-KXX-4-MS 12 -SI
HD / LD
0.015 730 1240 LU3-400 S7FO8
ADV200-WA-74000-XXX-4-SL
0.015 730 1240 LU3-400 S7FO8
ADV200-WA-74000-XXX-4-SL
0.015 730 1240 LU3-400 S7FO8
Note ! Chokes dimensions and weights are listed in the Gefran Accessories catalogue (1S9I09).
