ADV200 WA • Quick start up guide - Specification and installation 127
Sizes
AC mains voltage 400V -15% … 480V +10%
Heavy duty Light duty
EN 61800-3 :
Category / Environment
/ Motor cable length
Type Code Type Code
500 kW
ADV200-WA-72500-KXX-4-MS 05 -SI
EMI-480-400 S7DGI EMI-480-600 S7DGL C3 / 2nd / 100 m
ADV200-WA-72500-XXX-4-SL
EMI-480-400 S7DGI EMI-480-600 S7DGL C3 / 2nd / 100 m
630 kW
ADV200-WA-73150-KXX-4-MS 06 -SI
EMI-480-600 S7DGL EMI-480-600 S7DGL C3 / 2nd / 100 m
ADV200-WA-73150-XXX-4-SL
EMI-480-600 S7DGL EMI-480-600 S7DGL C3 / 2nd / 100 m
710 kW
ADV200-WA-73550-KXX-4-MS 07 -SI
EMI-480-800 S7DGM EMI-480-800 S7DGM C3 / 2nd / 100 m
ADV200-WA-73550-XXX-4-SL
EMI-480-800 S7DGM EMI-480-800 S7DGM C3 / 2nd / 100 m
800 kW
ADV200-WA-74000-KXX-4-MS 08 -SI
EMI-480-800 S7DGM EMI-480-800 S7DGM C3 / 2nd / 100 m
ADV200-WA-74000-XXX-4-SL
EMI-480-800 S7DGM EMI-480-800 S7DGM C3 / 2nd / 100 m
1000 kW
ADV200-WA-73550-KXX-4-MS 10 -SI
EMI-480-800 S7DGM EMI-480-800 S7DGM C3 / 2nd / 100 m
ADV200-WA-73550-XXX-4-SL
EMI-480-800 S7DGM EMI-480-800 S7DGM C3 / 2nd / 100 m
ADV200-WA-73550-XXX-4-SL
EMI-480-800 S7DGM EMI-480-800 S7DGM C3 / 2nd / 100 m
1200 kW
ADV200-WA-74000-KXX-4-MS 12 -SI
EMI-480-800 S7DGM EMI-480-800 S7DGM C3 / 2nd / 100 m
ADV200-WA-74000-XXX-4-SL
EMI-480-800 S7DGM EMI-480-800 S7DGM C3 / 2nd / 100 m
ADV200-WA-74000-XXX-4-SL
EMI-480-800 S7DGM EMI-480-800 S7DGM C3 / 2nd / 100 m
Sizes
AC mains voltage 400V -15% … 480V +10%
Heavy duty Light duty
EN 61800-3 :
Category / Environment
/ Motor cable length
Type Code Type Code
≥ 1015 ECF3 F4ZZ2 ECF3 F4ZZ2 C4 / 2nd / 100 m
Note ! For internal filter specification see chapter 5.1.5.
Filters dimensions and weights are listed in the Gefran Accessories catalogue (1S9I09).
