ADV200 WA • Quick start up guide - Specification and installation 27
Sizes
Bars: L1 - L2 - L3 - C - D - U - V - W
Recommended cable cross-
section
Lock screw
diameter
Tightening torque
(min)
(mm
2
) AWG / kcmil (mm) (Nm)
500kW
ADV200-WA-72500-KXX-4-MS 05 -SI
2 x 100 2 x AWG 4/0 M10 (U,V,W=M12) 50 (M10) / 75 (M12)
ADV200-WA-72500-XXX-4-SL
2 x 100 2 x AWG 4/0 M10 (U,V,W=M12) 50 (M10) / 75 (M12)
630kW
ADV200-WA-73150-KXX-4-MS 06 -SI
2 x 150 2 x kcmil 300 M10 (U,V,W=M12) 50 (M10) / 75 (M12)
ADV200-WA-73150-XXX-4-SL
2 x 150 2 x kcmil 300 M10 (U,V,W=M12) 50 (M10) / 75 (M12)
710kW
ADV200-WA-73550-KXX-4-MS 07 -SI
2 x 185 2 x kcmil 350 M10 (U,V,W=M12) 50 (M10) / 75 (M12)
ADV200-WA-73550-XXX-4-SL
2 x 185 2 x kcmil 350 M10 (U,V,W=M12) 50 (M10) / 75 (M12)
800kW
ADV200-WA-74000-KXX-4-MS 08 -SI
2 x 185 2 x kcmil 350 M10 (U,V,W=M12) 50 (M10) / 75 (M12)
ADV200-WA-74000-XXX-4-SL
2 x 185 2 x kcmil 350 M10 (U,V,W=M12) 50 (M10) / 75 (M12)
1000kW
ADV200-WA-73550-KXX-4-MS 10 -SI
2 x 185 2 x kcmil 350 M10 (U,V,W=M12) 50 (M10) / 75 (M12)
ADV200-WA-73550-XXX-4-SL
2 x 185 2 x kcmil 350 M10 (U,V,W=M12) 50 (M10) / 75 (M12)
ADV200-WA-73550-XXX-4-SL
2 x 185 2 x kcmil 350 M10 (U,V,W=M12) 50 (M10) / 75 (M12)
1200kW
ADV200-WA-74000-KXX-4-MS 12 -SI
2 x 185 2 x kcmil 350 M10 (U,V,W=M12) 50 (M10) / 75 (M12)
ADV200-WA-74000-XXX-4-SL
2 x 185 2 x kcmil 350 M10 (U,V,W=M12) 50 (M10) / 75 (M12)
ADV200-WA-74000-XXX-4-SL
2 x 185 2 x kcmil 350 M10 (U,V,W=M12) 50 (M10) / 75 (M12)
Sizes
Connection
Recommended cable
cross-section
Lock screw
diameter
Recommended
stripping
Tightening
torque (min)
(mm
2
) AWG / kcmil (mm) (mm) (Nm)
500kW
ADV200-WA-72500-KXX-4-MS 05 -SI
150 300 kcmil M10 Eyelet 50
ADV200-WA-72500-XXX-4-SL
150 300 kcmil M10 Eyelet 50
630kW
ADV200-WA-73150-KXX-4-MS 06 -SI
150 300 kcmil M10 Eyelet 50
ADV200-WA-73150-XXX-4-SL
150 300 kcmil M10 Eyelet 50
710kW
ADV200-WA-73550-KXX-4-MS 07 -SI
185 350 kcmil M10 Eyelet 50
ADV200-WA-73550-XXX-4-SL
185 350 kcmil M10 Eyelet 50
800kW
ADV200-WA-74000-KXX-4-MS 08 -SI
185 350 kcmil M10 Eyelet 50
ADV200-WA-74000-XXX-4-SL
185 350 kcmil M10 Eyelet 50
1000kW
ADV200-WA-73550-KXX-4-MS 10 -SI
185 350 kcmil M10 Eyelet 50
ADV200-WA-73550-XXX-4-SL
185 350 kcmil M10 Eyelet 50
ADV200-WA-73550-XXX-4-SL
185 350 kcmil M10 Eyelet 50
1200kW
ADV200-WA-74000-KXX-4-MS 12 -SI
185 350 kcmil M10 Eyelet 50
ADV200-WA-74000-XXX-4-SL
185 350 kcmil M10 Eyelet 50
ADV200-WA-74000-XXX-4-SL
185 350 kcmil M10 Eyelet 50
