42 ADV200 WA • Quick start up guide - Specification and installation
Sizes
Version before 2009/125/CE (ErP regulation)
Terminals
U3 V3 PE 31 32
500 kW
630 kW
1 x 230V / 50/60Hz,
2.4A (50Hz) - 3.3A
(60Hz)
(x 2)
Ground
250V/10A contact (x 2)
Motor over temperature contact management terminals 31-32:
Closed: Internal fan in operation and powered;
Open: Internal fan in over temperature alarm and/or input power supply
not available.
Power the internal fan (max 600W) with a single-phase voltage on terminals U3/V3. ( x 2).
Type of fan compliant 2009/125/CE (ErP)
ADV200 WA starting from S/N 33GC017331
Terminals
U3 V3 W3 PE 31 32
3 x 400V / 50/Hz,
1.15Arms ... 3
x 460V / 60Hz,
1.4Arms
(x 2)
Ground
250V/2A contact (x 2)
Motor over temperature contact management terminals 31-32:
Closed: Internal fan in operation
Open: Internal fan in over temperature alarm
Power the internal fan ( 570W @400V, 930W @460V ) with a three-phase voltage on terminals U3/V3/
W3 (x 2).
Sizes
Terminals
U3 V3 W3 PE 31 32
710 kW
800 kW
3 x 400V / 50Hz,
1,55Arms (x 2)
or
3 x 460V / 60Hz,
1,7Arms (x 2) (*)
Ground
250V/10A contact (x 2)
Motor over temperature contact management terminals 31-32:
Closed: Internal fan in operation
Open: Internal fan in over temperature alarm
Power the internal fan (max 1200W) with a three-phase voltage on terminals U3/V3/W3. (x 2).
1000 kW
1200 kW
3 x 400V / 50Hz,
1,55Arms (x 3)
or
3 x 460V / 60Hz,
1,7Arms (x 3) (*)
Ground
250V/10A contact (x 3)
Motor over temperature contact management terminals 31-32:
Closed: Internal fan in operation
Open: Internal fan in over temperature alarm
Power the internal fan (max 1200W) with a three-phase voltage on terminals U3/V3/W3 (x 3).
(*) ADV200 WA-73550-KXX-4A and ADV200 WA-74000-KXX-4A models.
Make sure the sequence of the three-phase fan power supply phases is the same as that shown on
the relative drive terminals. If not, the air flow will be inadequate to ensure correct cooling..
Caution
