ADV200 WA • Quick start up guide - Specification and installation 51
Sizes Technical data of the Internal Braking Units (Duty 50%)
Nominal current of the
internal braking unit
Irms (A)
Peak current
Ipk (A)
Minimum braking
resistance value
Rbr (Ω)
1015
Internal Braking
Units (standard
internal)
5.7 8 100
1022 5.7 8 100
1030 5.7 8 100
1040 5.7 8 100
1055 5.7 8 100
2075 8.5 12 67
2110 8.5 12 67
2150 15.5 22 36
3185 22 31 26
3220 37 53 15
3300 37 53 15
4370
Internal Braking
Units (standard
internal)
57 80 10
4450 57 80 10
4550 76 107 7.5
5750 76 107 7.5
≥ 5900
and
ADV200 WA-
...-DC
External Braking Unit
(optional)
See the BUy manual.
