ADV200 WA • Quick start up guide - Specification and installation 83
The analog output signal can be adjusted using Analog out 1 scale (PAR: 1808)
and Analog out 2 scale parameters (PAR:1810).
• Keypad
Use the LOC / REM key with the Enable input open (terminal 7 on terminal strip
T2) to control running, to stop and reverse the direction of rotation of the motor
using the operator keypad on the drive. Use the potentiometer or an analog signal
to control speed.
For information on how to use a digital speed reference, see the example on chap-
ter 7.3.3. The reference can have a positive or negative value, making it possible to
reverse the direction of rotation of the motor.
When the Enable input is closed, to enable motor running press START. The mo-
tor starts the acceleration ramp and moves to the speed set in the FWD direction.
With the motor running you can adjust the speed using the Dig ramp ref 1 param-
eter (PAR: 600) and the acceleration/deceleration ramps using Acceleration time
0 (PAR: 700) and Deceleration time 0 (PAR: 702).
To change the direction of rotation press FWD/REV.
To stop the motor with the deceleration ramp, press STOP.
If the Enable contact is opened the inverter bridge is immediately disabled and the
motor stops for inertia
To return to control using the terminal strip commands and analog speed refer-
ence:
1. Stop the motor
2. Open the Enable terminal
3. Press LOC / REM key.
Note ! For more customizations and any information that is not included in this initial customization guide, see
the description of the parameters in this manual.
