ADV200 WA • Quick start up guide - Specification and installation 91
XXXXH-X The XXXXH-X code indicates the reason for the error: make a note of this to
discuss it with the service centre.
Solution: Refer to the documentation concerning the enabled application.
52
53
54
55
Analog 1 Err
Analog 2 Err
Analog 3 Err
Analog 4 Err
Condition: If an analog measurement is out of the allowed range an “Analog X err” alarm
is generated. This control is only possible for 4-20 mA, PT100, PT1000, NI1000 probes. For
temperature probes both short-circuits and power loss on the cable are detected. For 4-20 mA
probes only power loss on the cable is detected.
Analog 1 Err = Error on analog channel 1
Analog 2 Err = Error on analog channel 2
Analog 3 Err = Error on analog channel 1 of expansion card
Analog 4 Err = Error on analog channel 2 of expansion card
Solution: Check connections.
