AGy -L 225
LCD Display DESCRIPTION LCD Selection Description
Def.
Min
Max
Unit
Variat.
IPA
PARAMETER PICK LIST
Code
d.253 LCW Fr PLC(8-15) Monitor of the control bits generated by the internal sequencer.
Bit8to15
69
d.254 LCW FrPLC(16-24) Monitor of the control bits generated by the internal sequencer.
Bit 16 to 24
70
d.255 LSW (0-7) Monitor of the drive status. Bit 0 to 7
71
d.300 EncPulses/Sample Number of encoder pulses, recorded in the time interval defined
by parameter I.504.
1/100 035
d.301 Encoder freq Encoder frequency reading (Motor frequency)
Hz 0.01 036
d.302 Encoder speed Encoder speed reading (d.000)*(P.600)
0.01/1 037
d.350 Option 1 state Drive option 1 state (expansion board type programmed)
038
d.351 Option 2 state Drive option 2 state (expansion board type programmed)
039
d.353 Sbi state
0 Wait parametrization 059
1 Wait configuration
2 Data exchange
3 Error
d.354 Sbi baudrate
0 12 Mbit / s 060
1 6Mbit/s
2 3Mbit/s
3 1.5 Mbit / s
4 500 Kbit / s
5 187.5 Kbit / s
6 93.75 Kbit / s
7 45.45 Kbit / s
8 19.2 Kbit / s
15 unknown
d.400 PID reference PID reference signal
% 0.1 041
d.401 PID feedback PID feedback signal
% 0.1 042
d.402 PID error PID error signal
% 0.1 043
d.403 PID integr comp PID integral component
% 0.1 044
d.404 PID output PID output signal
% 0.1 045
d.450 Mdplc error Status of internal sequencer
0 No error
1 Internal sequencer error 62
d.500 Lift space Space needed to accelerate the car from zero to max speed
and then decelerate back to zero
?
0.01 63
d.501 Lift accel space Space needed to accelerate the car from zero to max speed
?
0.01 64
d.502 Lift decel space Space needed to decelerate the car from max speed to zero
?
0.01 65
d.800 1st alarm-latest Last alarm stored by the drive alarm list
See paragraph 9.3 046
d.801 2nd alarm Second to last alarm
047
d.802 3rd alarm Third to last alarm
048
d.803 4th alarm Fourth to last alarm
049
d.950 Drive rated curr Drive rated current (it depends on the drive size)
0.1 050
d.951 SW version (1/2) Software version - part 1
03.01 0.01 051
d.952 SW version (2/2) Software version - part 2
00.00 0.01 052
d.957 Drive size Drive size code
0 0.75kW - 230/400/460V 057
1 1.5kW - 230/400/460V
2 2.2kW - 230/400/460V
3 3kW - 230/400/460V
4 4kW - 230/400/460V
5 5.5kW - 230/400/460V
6 7.5kW - 230/400/460V
7 11kW - 230/400/460V
8 15kW - 230/400/460V
9 22kW - 230/400/460V
10 30kW - 230/400/460V
11 37kW - 230/400/460V
12 45kW - 230/400/460V
13 55kW - 230/400/460V
14 75kW - 230/400/460V
15 90kW - 230/400/460
16 110kW - 230/400/460V
17 132kW - 230/400/460V
18 160kW - 230/400/460V
21 18.5kW - 230/400460
25 200kW - 230/400460
d.958 Drive cfg type Drive configuration type
[0]Standard:400
[1]American:460
Standard: 400Vac, 50Hz
American: 460Vac, 60Hz
061
d.999 Display Test Drive display test
099
Communication speed between SBI and Master
Communication state between SBI and Master
