LCD Display DESCRIPTION LCD Selection Description
Def.
Min
Max
Unit
Variat.
IPA
PARAMETER PICK LIST
Code
S.000 Mains voltage Rated value of the line voltage
230 400 230 480 V
380
400
420
440
460
480
S.001 Mains frequency Rated value of the line frequency
50 50 50 60 Hz
60
S.100 Base voltage Motor base (rated) voltage
380 50 528 V 1 413
(P.061)
S.101 Base frequency Rated frequency of the motor
50 25 250 Hz 0.1 414
(P.062)
S.150 Motor rated curr Rated current of the motor
(*) (*) (*) A 0.1 406
(P.040)
S.151 Motor pole pairs Pole Pairs of the motor
2 1 60 0.01 407
(P.041)
S.152 Motor power fact Motor power factor
(*) 0.01 1 0.01 408
(P.042)
S.153 Motor stator R Measurement of the stator resistance of the motor
(*) 0 99.99 ohm 409
(P.043)
S.170 Measure stator R Motor Autotune command
(1) (1) (1) (2)
(2)
S.180 Car max speed Speed of the lift car when the inverter output frequency is equal
to S.101
0.50 0.01 5.00 m/s 0.01 1323
(A.090)
S.200 Frequency ref 0 Digital reference frequency 0
10.0 -F.020 F.020 311 (F.100)
S.201 Frequency ref 1 Digital reference frequency 1
50.0 -F.020 F.020 312 (F.101)
S.202 Frequency ref 2 Digital reference frequency 2
0 -F.020 F.020 313 (F.102)
S.203 Frequency ref 3 Digital reference frequency 3
0 -F.020 F.020 314 (F.103)
S.204 Frequency ref 4 Digital reference frequency 4
0 -F.020 F.020 315 (F.104)
S.205 Frequency ref 5 Digital reference frequency 5
0 -F.020 F.020 316 (F.105)
S.206 Frequency ref 6 Digital reference frequency 6
0 -F.020 F.020 317 (F.106)
S.207 Frequency ref 7 Digital reference frequency 7
0 -F.020 F.020 318 (F.107)
S.220 Smooth start frq Frequency reference during smooth start
2.0 -F.020 F.020 327 (F.116)
S.225 Ramp factor 1 Multiplier for acc/dec and jerks of ramp sets 1 and 3
1.00 0.01 2.50 0.01 1324
(A.091)
S.226 Ramp factor 2 Multiplier for acc/dec and jerks of ramp sets 2 and 4
1.00 0.01 2.50 0.01 1327
(A.092)
S.230 Jerk acc ini 1 Jerk applied at the beginning of an acceleration with ramp set 1
0.50 0.01 10.00
m/s
3
0.01 343 (F.251)
S.231 Acceleration 1 Linear acceleration with ramp set 1
0.60 0.01 5.00
m/s
2
0.01 329 (F.201)
S.232 Jerk acc end 1 Jerk applied at the end of an acceleration with ramp set 1
1.40 0.01 10.00
m/s
3
0.01 344 (F.252)
S.233 Jerk dec ini 1 Jerk applied at the beginning of a deceleration with ramp set 1
1.40 0.01 10.00
m/s
3
0.01 345 (F.253)
S.234 Deceleration 1 Linear deceleration with ramp set 1
0.60 0.01 5.00
m/s
2
0.01 330 (F.202)
S.235 Jerk dec end 1 Jerk applied at the end of a deceleration with ramp set 1
1.00 0.01 10.00
m/s
3
0.01 346 (F.254)
S.240 Jerk acc ini 2 Jerk applied at the beginning of an acceleration with ramp set 2
1.00 0.01 10.00
m/s
3
0.01 347 (F.255)
S.241 Acceleration 2 Linear acceleration with ramp set 2
0.60 0.01 5.00
m/s
2
0.01 331 (F.203)
S.242 Jerk acc end 2 Jerk applied at the end of an acceleration with ramp set 2
1.40 0.01 10.00
m/s
3
0.01 348 (F.256)
S.243 Jerk dec ini 2 Jerk applied at the beginning of a deceleration with ramp set 2
1.40 0.01 10.00
m/s
3
0.01 349 (F.257)
START-UP
