MagicControl 4.0 (CM40) Operation

43
The key turns orange and the axis is selected.
– Only selected axes can be started.
3. Press the key
– Start axes
4. Press the key
– Stop axes
5. Touch the input field to change the position of the respective axis
Coating programs
1. Press the symbol to load coating programs
Fig.
27
: Coating programs
Confirm program selection
Copy data
Insert data
Exit screen
Scroll bar
Delete entry in search field
Datasearch by alphanumeric entry
Data search by program number entry:
– The topmost entry is set to the number searched for
Currently selected line
Currently loaded object that is available for editing
