OptiStar CG08(-C) Product description • 17
Typical properties – Characteristics of the functions
Operating modes
The OptiStar CG08(-C) gun control unit has two operating modes.
Predefined operating mode (Preset mode)
The OptiStar CG08(-C) gun control unit has three preset application modes:
- Application mode for flat parts
This application mode is suitable for the coating of simple,
flat workpieces without larger cavities.
- Application mode for complex parts
This application mode is suitable for the coating of three-
dimensional workpieces with complex shapes (e.g. profiles).
- Application mode for recoating parts already coated
This application mode is suitable for the overcoating of
workpieces which are already coated.
In this operating modes, current (µA) and high voltage (kV) are preset, while
powder and air volumes can be set and stored for each application mode.
Adjustable operating mode (Program mode)
In this operating mode, 250 individually definable programs (P001-P250)
are available. These programs are automatically saved and can be
recalled again as the application requires.
The values for current, high voltage, powder output, total air and
electrode rinsing air can be set as needed for a given application.
NOTE:
The settings defined in the 250 programs and 3 application modes
are automatically stored, without confirmation!
